A blue laser is a laser that emits electromagnetic radiation with a wavelength between 360 and 480 nanometres, which the human eye sees as blue or violet.

Blue beams are produced by helium-cadmium gas lasers at 441.6 nm, and argon-ion lasers at 458 and 488 nm. Semiconductor lasers with blue beams are typically based on gallium(III) nitride (GaN; violet color) or indium gallium nitride (often true blue in color, but also able to produce other colors). Both blue and violet lasers can also be constructed using frequency-doubling of infrared laser wavelengths from diode lasers or diode-pumped solid-state lasers.

Diode lasers which emit light at 445 nm are becoming popular as handheld lasers. Lasers emitting wavelengths below 445 nm appear violet (but are sometimes called blue lasers). Some of the most commercially common blue lasers are the diode lasers used in Blu-ray applications which emit 405 nm 'violet' light, which is a short enough wavelength to cause fluorescence in some chemicals, in the same way as radiation further into the ultraviolet ('black light') does. Light of a shorter wavelength than 400 nm is classified as ultraviolet.

Devices that employ blue laser light have applications in many areas ranging from optoelectronic data storage at high density to medical applications.

• 1History

History[edit]

Semiconductor lasers[edit]

Red lasers can be built on gallium arsenide (GaAs) semiconductors, upon which a dozen layers of atoms are placed to form the part of the laser that generates light from quantum wells. Using methods similar to those developed for silicon, the substrate can be built free of the defects called dislocations, and the atoms laid down so the distance between the ones making up the ground and those of the quantum wells are the same.

However, the best semiconductor for blue lasers is gallium nitride (GaN) crystals, which are much harder to manufacture, requiring higher pressures and temperatures, similar to the ones that produce synthetic diamonds, and the use of high-pressure nitrogen gas. The technical problems seemed insurmountable, so researchers since the 1960s have sought to deposit GaN on a base of readily available sapphire. But a mismatch between the structures of sapphire and gallium nitride created too many defects.

In 1992 Japanese inventor Shuji Nakamura invented the first efficient blue LED, and four years later, the first blue laser. Nakamura used the material deposited on the sapphire substrate, although the number of defects remained too high (10⁶–10¹⁰/cm²) to easily build a high-power laser.

In the early 1990s the Institute of High Pressure Physics at the Polish Academy of Sciences in Warsaw (Poland), under the leadership of Dr. Sylwester Porowski developed technology to create gallium nitride crystals with high structural quality and fewer than 100 defects per square centimeter — at least 10,000 times better than the best sapphire-supported crystal.^[1]

In 1999, Nakamura tried Polish crystals, producing lasers with twice the yield and ten times the lifetime — 3,000 hours at 30 mW.

A further development of the technology has led to mass production of the device. Today, blue lasers use a sapphire surface covered with a layer of gallium nitride (this technology is used by Japanese company Nichia, which has an agreement with Sony), and blue semiconductor lasers use a gallium nitride mono-crystal surface (Polish company TopGaN^[2]).

After 10 years, Japanese manufacturers mastered the production of a blue laser with 60 mW of power, making them applicable for devices that read a dense high-speed stream of data from Blu-ray, BD-R, and BD-RE. Polish technology is cheaper than Japanese but has a smaller share of the market. There is one more Polish high-tech company which creates gallium nitride crystal – Ammono,^[3][4] but this company does not produce blue lasers.

For his work, Nakamura received the Millennium Technology Prize awarded in 2006, and a Nobel Prize for Physics awarded in 2014.^[5]

Until the late 1990s, when blue semiconductor lasers were developed, blue lasers were large and expensive gas laser instruments which relied on population inversion in rare gas mixtures and needed high currents and strong cooling.

Thanks to prior development of many groups, including, most notably, Professor Isamu Akasaki's group, Shuji Nakamura at Nichia Corporation and Sony Corporation in Anan (Tokushima-ken, Japan) made a series of inventions and developed commercially viable blue and violet semiconductor lasers. The active layer of the Nichia devices was formed from InGaNquantum wells or quantum dots spontaneously formed via self-assembly. The new invention enabled the development of small, convenient and low-priced blue, violet, and ultraviolet (UV) lasers, which had not been available before, and opened the way for applications such as high-density HD DVD data storage and Blu-ray discs. The shorter wavelength allows it to read discs containing much more information.^[6]

Isamu Akasaki, Hiroshi Amano and Shuji Nakamura won the 2014 Nobel Prize in Physics 'for the invention of efficient blue light-emitting diodes which has enabled bright and energy-saving white light sources'.^[7]

Frequency doubled semiconductor lasers[edit]

Infrared lasers based on semiconductors are readily available since decades, for instance as pump source for telecom or solid state lasers. These can be frequency-doubled to the blue range using standard nonlinear crystals.

Violet lasers may be constructed directly with GaN (gallium nitride) semiconductors, as noted. However, a few higher-powered (120 mW) 404–405 nm 'violet' laser pointers have become available which are not based on GaN, but also use frequency-doubler technology starting from 1 watt 808 nm gallium arsenide infrared diode lasers being directly doubled, without a longer-wave diode-pumped solid state laser interposed between diode laser and doubler-crystal.

Highest powers and wavelength tunability can be reached when the frequency doubling process is resonator enhanced, resulting in Watt-class sources spanning across the visible wavelength range. For instance, in ^[8] 2.6 W of output power around 400 nm were demonstrated.

Diode-pumped solid state lasers[edit]

Blue laser pointers, which became available around 2006, have the same basic construction as DPSS green lasers. They most commonly emit light at 473 nm, which is produced by frequency doubling of 946 nm laser radiation from a diode-pumped Nd:YAG or Nd:YVO4 crystal. Neodymium-doped crystals usually produce a principal wavelength of 1064 nm, but with the proper reflective coating mirrors can be also made to lase at other non-principal neodymium wavelengths, such as the 946 nm transition used in blue-laser applications. For high output power BBO crystals are used as frequency doublers; for lower powers, KTP is used. Output powers available are up to 5000 mW. Conversion efficiency for producing 473 nm laser radiation is inefficient with some of the best lab produced results coming in at 10-15% efficient at converting 946 nm laser radiation to 473 nm laser radiation. In practical applications, one can expect this to be even lower. Due to this low conversion efficiency, use of a 1000 mW IR diode results in at most 150 mW of visible blue light.

Blue lasers can also be fabricated directly with InGaN semiconductors, which produce blue light without frequency-doubling. 445 nm through 465 nm blue laser diodes are currently available on the open market. The devices are significantly brighter than 405 nm laser diodes, since the longer wavelength is closer to the peak sensitivity of the human eye. Commercial devices like laser projectors have driven down the prices on these diodes.

Appearance[edit]

The violet 405 nm laser (whether constructed from GaN or frequency-doubled GaAs laser diodes) is not in fact blue, but appears to the eye as violet, a color for which a human eye has a very limited sensitivity. When pointed at many white objects (such as white paper or white clothes which have been washed in certain washing powders) the visual appearance of the laser dot changes from violet to blue, due to fluorescence of brightening dyes.

For display applications which must appear 'true blue', a wavelength of 445–450 nm is required. With advances in production, and commercial sales of low-cost laser projectors, 445 nm InGaN laser diodes have dropped in price.

Applications[edit]

Areas of application of the blue laser include:

• High-definition Blu-ray players
• DLP and 3LCD projectors
• Telecommunications
• Information technology
• Environmental monitoring
• Electronic equipment
• Medical diagnostics
• Handheld projectors and displays

See also[edit]

References[edit]

1. ^Sylwester Porowski: blue laser. Poland.gov.pl (2001-12-12). Retrieved on 2010-10-26.
2. ^TopGaN technology of blue/violet laser diodes
3. ^[1] A little Polish company you've never heard of is beating the tech titans in a key technology of the 21st century
4. ^Home Site – Ammono – semiconductor manufacturing. Ammono.com. Retrieved on 2010-10-26.
5. ^Shuji Nakamura wins the 2006 Millennium Technology Prize. Gizmag.com (2006-05-17). Retrieved on 2010-10-26.
6. ^Arpad A. Bergh, Blue laser diode (LD) and light emitting diode (LED)applications, phys. stat. sol. (a) 201, No. 12, 2740–2754 (2004)
7. ^NobelPrize.org Press Release (7 October 2014): The Royal Swedish Academy of Sciences has decided to award the Nobel Prize in Physics for 2014 to Isamu Akasaki (Meijo University, Nagoya, Japan and Nagoya University, Japan), Hiroshi Amano (Nagoya University, Japan) and Shuji Nakamura (University of California, Santa Barbara, CA, USA) “for the invention of efficient blue light-emitting diodes which has enabled bright and energy-saving white light sources”
8. ^U. Eismann et al., Active and passive stabilization of a high power violet frequency-doubled diode laser, CLEO: Applications and Technology, pages JTu5A-65 (2016)

SEM image of a commercial laser diode with its case and window cut away. The anode connection on the right has been accidentally broken by the case cut process.A laser diode, ( LD), injection laser diode ( ILD), or diode laser is a device similar to a in which a is created at the diode's.Laser diodes can directly convert electrical energy into light.

Driven by voltage, the doped p-n-transition allows for of an electron with a. Due to the drop of the electron from a higher energy level to a lower one, radiation, in the form of an emitted photon is generated. This is spontaneous emission. Stimulated emission can be produced when the process is continued and further generate light with the same phase, coherence and wavelength.The choice of the semiconductor material determines the wavelength of the emitted beam, which in today's laser diodes range from infra-red to the UV spectrum. Laser diodes are the most common type of lasers produced, with a wide range of uses that include, // disc reading/recording, and illumination. With the use of a phosphor like that found on white, Laser diodes can be used for general illumination.

Semi-conductor lasers (660 nm, 635 nm, 532 nm, 520 nm, 445 nm, 405 nm)A laser diode is electrically a. The active region of the laser diode is in the intrinsic (I) region, and the carriers (electrons and holes) are pumped into that region from the N and P regions respectively. While initial diode laser research was conducted on simple P-N diodes, all modern lasers use the double-hetero-structure implementation, where the carriers and the photons are confined in order to maximize their chances for recombination and light generation. Unlike a regular diode, the goal for a laser diode is to recombine all carriers in the I region, and produce light.

Thus, laser diodes are fabricated using semiconductors. The laser diode structure is grown using one of the techniques, usually starting from an N substrate, and growing the I doped active layer, followed by the P doped, and a contact layer. The active layer most often consists of, which provide lower threshold current and higher efficiency. Electrical and optical pumping Laser diodes form a subset of the larger classification of semiconductor p- n junction diodes. Forward electrical bias across the laser diode causes the two species of – and – to be 'injected' from opposite sides of the p- n junction into the depletion region. Holes are injected from the p-doped, and electrons from the n-doped, semiconductor. (A, devoid of any charge carriers, forms as a result of the difference in electrical potential between n- and p-type semiconductors wherever they are in physical contact.) Due to the use of charge injection in powering most diode lasers, this class of lasers is sometimes termed 'injection lasers,' or 'injection laser diode' (ILD).

As diode lasers are semiconductor devices, they may also be classified as semiconductor lasers. Either designation distinguishes diode lasers from.Another method of powering some diode lasers is the use of. Optically pumped semiconductor lasers (OPSL) use a III-V semiconductor chip as the gain medium, and another laser (often another diode laser) as the pump source. OPSL offer several advantages over ILDs, particularly in wavelength selection and lack of interference from internal electrode structures. A further advantage of OPSLs is invariance of the beam parameters - divergence, shape, and pointing - as pump power (and hence output power) is varied, even over a 10:1 output power ratio. Generation of spontaneous emission When an electron and a hole are present in the same region, they may or 'annihilate' producing a — i.e., the electron may re-occupy the energy state of the hole, emitting a photon with energy equal to the difference between the electron's original state and hole's state.

(In a conventional semiconductor junction diode, the energy released from the recombination of electrons and holes is carried away as, i.e., lattice vibrations, rather than as photons.) Spontaneous emission below the produces similar properties to an. Spontaneous emission is necessary to initiate laser oscillation, but it is one among several sources of inefficiency once the laser is oscillating.Direct and indirect bandgap semiconductors The difference between the photon-emitting semiconductor laser and a conventional phonon-emitting (non-light-emitting) semiconductor junction diode lies in the type of semiconductor used, one whose physical and atomic structure confers the possibility for photon emission.

These photon-emitting semiconductors are the so-called semiconductors. The properties of silicon and germanium, which are single-element semiconductors, have bandgaps that do not align in the way needed to allow photon emission and are not considered 'direct.' Other materials, the so-called compound semiconductors, have virtually identical crystalline structures as silicon or germanium but use alternating arrangements of two different atomic species in a checkerboard-like pattern to break the symmetry. The transition between the materials in the alternating pattern creates the critical ' property., and are all examples of compound semiconductor materials that can be used to create junction diodes that emit light. A simple and low power metal enclosed laser diode Generation of stimulated emission In the absence of stimulated emission (e.g., lasing) conditions, electrons and holes may coexist in proximity to one another, without recombining, for a certain time, termed the 'upper-state lifetime' or 'recombination time' (about a nanosecond for typical diode laser materials), before they recombine. A nearby photon with energy equal to the recombination energy can cause recombination.

This generates another photon of the same frequency, and, travelling in the same direction as the first photon. This means that stimulated emission will cause gain in an optical wave (of the correct wavelength) in the injection region, and the gain increases as the number of electrons and holes injected across the junction increases. The spontaneous and stimulated emission processes are vastly more efficient in semiconductors than in semiconductors; therefore is not a common material for laser diodes.Optical cavity and laser modes As in other lasers, the gain region is surrounded with an to form a laser.

In the simplest form of laser diode, an optical waveguide is made on that crystal's surface, such that the light is confined to a relatively narrow line. The two ends of the crystal are cleaved to form perfectly smooth, parallel edges, forming a resonator. Photons emitted into a mode of the waveguide will travel along the waveguide and be reflected several times from each end face before they exit. As a light wave passes through the cavity, it is amplified by, but light is also lost due to absorption and by incomplete reflection from the end facets.

Finally, if there is more amplification than loss, the diode begins to '.Some important properties of laser diodes are determined by the geometry of the optical cavity. Generally, the light is contained within a very thin layer, and the structure supports only a single optical mode in the direction perpendicular to the layers. In the transverse direction, if the waveguide is wide compared to the wavelength of light, then the waveguide can support multiple, and the laser is known as 'multi-mode'. These transversely multi-mode lasers are adequate in cases where one needs a very large amount of power, but not a small beam; for example in printing, activating chemicals, or other types of lasers.In applications where a small focused beam is needed, the waveguide must be made narrow, on the order of the optical wavelength.

This way, only a single transverse mode is supported and one ends up with a diffraction-limited beam. Such single spatial mode devices are used for optical storage, laser pointers, and fiber optics. Note that these lasers may still support multiple longitudinal modes, and thus can lase at multiple wavelengths simultaneously. The wavelength emitted is a function of the band-gap of the semiconductor material and the modes of the optical cavity.

In general, the maximum gain will occur for photons with energy slightly above the band-gap energy, and the modes nearest the peak of the gain curve will lase most strongly. The width of the gain curve will determine the number of additional 'side modes' that may also lase, depending on the operating conditions. Single spatial mode lasers that can support multiple longitudinal modes are called Fabry Perot (FP) lasers.

An FP laser will lase at multiple cavity modes within the gain bandwidth of the lasing medium. The number of lasing modes in an FP laser is usually unstable, and can fluctuate due to changes in current or temperature.Single spatial mode diode lasers can be designed so as to operate on a single longitudinal mode. These single frequency diode lasers exhibit a high degree of stability, and are used in spectroscopy and metrology, and as frequency references. Diagram of front view of a double heterostructure laser diode; not to scaleIn these devices, a layer of low material is sandwiched between two high bandgap layers. One commonly-used pair of materials is (GaAs) with (Al xGa (1-x)As). Each of the junctions between different bandgap materials is called a, hence the name 'double heterostructure laser' or DH laser. The kind of laser diode described in the first part of the article may be referred to as a homojunction laser, for contrast with these more popular devices.The advantage of a DH laser is that the region where free electrons and holes exist simultaneously—the —is confined to the thin middle layer.

This means that many more of the electron-hole pairs can contribute to amplification—not so many are left out in the poorly amplifying periphery. In addition, light is reflected within the heterojunction; hence, the light is confined to the region where the amplification takes place.Quantum well lasers. Diagram of front view of a simple quantum well laser diode; not to scaleIf the middle layer is made thin enough, it acts as a. This means that the vertical variation of the electron's, and thus a component of its energy, is quantized. The efficiency of a is greater than that of a bulk laser because the function of electrons in the quantum well system has an abrupt edge that concentrates electrons in energy states that contribute to laser action.Lasers containing more than one quantum well layer are known as multiple quantum well lasers. Multiple quantum wells improve the overlap of the gain region with the optical.Further improvements in the laser efficiency have also been demonstrated by reducing the quantum well layer to a or to a 'sea' of.Quantum cascade lasers.

Diagram of front view of a separate confinement heterostructure quantum well laser diode; not to scaleThe problem with the simple quantum well diode described above is that the thin layer is simply too small to effectively confine the light. To compensate, another two layers are added on, outside the first three. These layers have a lower than the centre layers, and hence confine the light effectively. Such a design is called a separate confinement heterostructure (SCH) laser diode.Almost all commercial laser diodes since the 1990s have been SCH quantum well diodes. Distributed Bragg Reflector lasers A ( DBR) is a type of single frequency laser diode. It is characterized by an consisting of an electrically or optically pumped gain region between two mirrors to provide feedback. One of the mirrors is a broadband reflector and the other mirror is wavelength selective so that gain is favored on a single longitudinal mode, resulting in lasing at a single resonant frequency.

The broadband mirror is usually coated with a low reflectivity coating to allow emission. The wavelength selective mirror is a periodically structured with high reflectivity. The diffraction grating is within a non-pumped, or passive region of the cavity.

A DBR laser is a monolithic single chip device with the grating etched into the semiconductor. DBR lasers can be edge emitting lasers. Alternative hybrid architectures that share the same topology include extended cavity diode lasers and volume Bragg grating lasers, but these are not properly called DBR lasers.Distributed feedback lasers. Main article:A (DFB) is a type of single frequency laser diode.

DFBs are the most common transmitter type in -systems. To stabilize the lasing wavelength, a diffraction grating is etched close to the p-n junction of the diode. This grating acts like an optical filter, causing a single wavelength to be fed back to the gain region and lase.

Since the grating provides the feedback that is required for lasing, reflection from the facets is not required. Thus, at least one facet of a DFB is. The DFB laser has a stable wavelength that is set during manufacturing by the pitch of the grating, and can only be tuned slightly with temperature. DFB lasers are widely used in optical communication applications where a precise and stable wavelength is critical.The threshold current of this DFB laser, based on its static characteristic, is around 11 mA. The appropriate bias current in a linear regime could be taken in the middle of the static characteristic (50 mA).Several techniques have been proposed in order to enhance the single-mode operation in these kinds of lasers by inserting an onephase-shift (1PS) or multiple-phase-shift (MPS) in the uniform Bragg grating. However, multiple-phase-shift DFB lasers represent the optimal solution because they have the combination of higher side-mode suppression ratio and reduced spatial hole-burning.Vertical-cavity surface-emitting laser.

Diagram of a simple VCSEL structure; not to scale(VCSELs) have the optical cavity axis along the direction of current flow rather than perpendicular to the current flow as in conventional laser diodes. The active region length is very short compared with the lateral dimensions so that the radiation emerges from the surface of the cavity rather than from its edge as shown in the figure. The reflectors at the ends of the cavity are made from alternating high and low refractive index quarter-wave thick multilayer.Such dielectric mirrors provide a high degree of wavelength-selective reflectance at the required free surface wavelength λ if the thicknesses of alternating layers d 1 and d 2 with refractive indices n 1 and n 2 are such that n 1 d 1 + n 2 d 2 = λ/2 which then leads to the constructive interference of all partially reflected waves at the interfaces.

But there is a disadvantage: because of the high mirror reflectivities, VCSELs have lower output powers when compared to edge-emitting lasers.There are several advantages to producing VCSELs when compared with the production process of edge-emitting lasers. Edge-emitters cannot be tested until the end of the production process.

If the edge-emitter does not work, whether due to bad contacts or poor material growth quality, the production time and the processing materials have been wasted.Additionally, because VCSELs emit the beam perpendicular to the active region of the laser as opposed to parallel as with an edge emitter, tens of thousands of VCSELs can be processed simultaneously on a three-inch gallium arsenide wafer. Furthermore, even though the VCSEL production process is more labor- and material-intensive, the yield can be controlled to a more predictable outcome. However, they normally show a lower power output level.Vertical-external-cavity surface-emitting-laser.

Main article:Vertical external-cavity surface-emitting lasers, or, are similar to VCSELs. In VCSELs, the mirrors are typically grown as part of the diode structure, or grown separately and bonded directly to the semiconductor containing the active region. VECSELs are distinguished by a construction in which one of the two mirrors is external to the diode structure.

As a result, the cavity includes a free-space region. A typical distance from the diode to the external mirror would be 1 cm.One of the most interesting features of any VECSEL is the small thickness of the semiconductor gain region in the direction of propagation, less than 100 nm. In contrast, a conventional in-plane semiconductor laser entails light propagation over distances of from 250 µm upward to 2 mm or longer. The significance of the short propagation distance is that it causes the effect of 'antiguiding' nonlinearities in the diode laser gain region to be minimized. The result is a large-cross-section single-mode optical beam which is not attainable from in-plane ('edge-emitting') diode lasers.Several workers demonstrated optically pumped VECSELs, and they continue to be developed for many applications including high power sources for use in industrial machining (cutting, punching, etc.) because of their unusually high power and efficiency when pumped by multi-mode diode laser bars. However, because of their lack of p-n junction, optically-pumped VECSELs are not considered 'diode lasers', and are classified as semiconductor lasers.

Electrically pumped VECSELs have also been demonstrated. Applications for electrically pumped VECSELs include projection displays, served by of near-IR VECSEL emitters to produce blue and green light.External-cavity diode lasers External-cavity diode lasers are which use mainly double heterostructures diodes of theAl xGa (1-x)As type.

The first external-cavity diode lasers used intracavityetalons and simple tuning Littrow gratings. Other designs include gratings in grazing-incidence configuration and multiple-prism grating configurations. Failure mechanisms. This section may be too technical for most readers to understand. Please to, without removing the technical details. ( July 2011) Laser diodes have the same and failure issues as.

In addition they are subject to (COD) when operated at higher power.Many of the advances in reliability of diode lasers in the last 20 years remain proprietary to their developers. The reliability of a laser diode can make or break a product line. Moreover, is not always able to reveal the differences between more-reliable and less-reliable diode laser products.At the edge of a diode laser, where light is emitted, a mirror is traditionally formed by the semiconductor wafer to form a specularly reflecting plane. This approach is facilitated by the weakness of the 110 in III-V semiconductor crystals (such as, etc.) compared to other planes. A scratch made at the edge of the wafer and a slight bending force causes a nearly atomically perfect mirror-like cleavage plane to form and propagate in a straight line across the wafer.But it so happens that the atomic states at the cleavage plane are altered (compared to their bulk properties within the crystal) by the termination of the perfectly periodic lattice at that plane.

At the cleaved plane have energy levels within the (otherwise forbidden) bandgap of the semiconductor.Essentially, as a result, when light propagates through the cleavage plane and transits to free space from within the semiconductor crystal, a fraction of the light energy is absorbed by the surface states where it is converted to heat by - interactions. This heats the cleaved mirror. In addition, the mirror may heat simply because the edge of the diode laser—which is electrically pumped—is in less-than-perfect contact with the mount that provides a path for heat removal.

The heating of the mirror causes the bandgap of the semiconductor to shrink in the warmer areas. The bandgap shrinkage brings more electronic band-to-band transitions into alignment with the photon energy causing yet more absorption.

This is, a form of, and the result can be melting of the facet, known as catastrophic optical damage, or COD.In the 1970s, this problem, which is particularly nettlesome for GaAs-based lasers emitting between 0.630 µm and 1 µm wavelengths (less so for InP-based lasers used for long-haul telecommunications which emit between 1.3 µm and 2 µm), was identified. Michael Ettenberg, a researcher and later Vice President at Laboratories' in, devised a solution. A thin layer of was deposited on the facet. If the aluminum oxide thickness is chosen correctly, it functions as an, reducing reflection at the surface. This alleviated the heating and COD at the facet.Since then, various other refinements have been employed. One approach is to create a so-called non-absorbing mirror (NAM) such that the final 10 µm or so before the light emits from the cleaved facet are rendered non-absorbing at the wavelength of interest.In the very early 1990s, SDL, Inc. Began supplying high power diode lasers with good reliability characteristics.

CEO Donald Scifres and CTO David Welch presented new reliability performance data at, e.g., Photonics West conferences of the era. The methods used by SDL to defeat COD were considered to be highly proprietary and were still undisclosed publicly as of June 2006.In the mid-1990s, IBM Research (Ruschlikon, ) announced that it had devised its so-called 'E2 process' which conferred extraordinary resistance to COD in GaAs-based lasers. This process, too, was undisclosed as of June 2006.Reliability of high-power diode laser pump bars (used to pump solid-state lasers) remains a difficult problem in a variety of applications, in spite of these proprietary advances.

Indeed, the physics of diode laser failure is still being worked out and research on this subject remains active, if proprietary.Extension of the lifetime of laser diodes is critical to their continued adaptation to a wide variety of applications.Applications. Laser diodes can be arrayed to produce very high power outputs, continuous wave or pulsed. Such arrays may be used to efficiently pump solid-state lasers for high average power drilling, burning or for.Laser diodes are numerically the most common laser type, with 2004 sales of approximately 733 million units,as compared to 131,000 of other types of lasers. Telecommunications, scanning and spectrometry Laser diodes find wide use in as easily modulated and easily coupled light sources for communication.

They are used in various measuring instruments, such as. Another common use is in.

Lasers, typically but later also, are common as. Both low and high-power diodes are used extensively in the printing industry both as light sources for scanning (input) of images and for very high-speed and high-resolution printing plate (output) manufacturing. And red laser diodes are common in, and technology. Lasers are used in and technology. Diode lasers have also found many applications in (LAS) for high-speed, low-cost assessment or monitoring of the concentration of various species in gas phase.

High-power laser diodes are used in industrial applications such as heat treating, cladding, seam welding and for pumping other lasers, such as.Uses of laser diodes can be categorized in various ways. Most applications could be served by larger solid-state lasers or optical parametric oscillators, but the low cost of mass-produced diode lasers makes them essential for mass-market applications. Diode lasers can be used in a great many fields; since light has many different properties (power, wavelength, spectral and beam quality, polarization, etc.) it is useful to classify applications by these basic properties.Many applications of diode lasers primarily make use of the 'directed energy' property of an optical beam.

In this category, one might include the, barcode readers, illuminators, designators, optical data recording, industrial sorting, industrial machining, and directed energy weaponry. Some of these applications are well-established while others are emerging.Medical uses : medicine and especially dentistry have found many new uses for diode lasers. The shrinking size and cost of the units and their increasing user friendliness makes them very attractive to clinicians for minor soft tissue procedures. Diode wavelengths range from 810 to 1,100, are poorly absorbed by soft tissue, and are not used for cutting. Soft tissue is not cut by the laser's beam, but is instead cut by contact with a hot charred glass tip.

The laser's irradiation is highly absorbed at the distal end of the tip and heats it up to 500 °C to 900 °C. Because the tip is so hot, it can be used to cut soft-tissue and can cause through. Diode lasers when used on soft tissue can cause extensive collateral thermal damage to surrounding tissue.As laser beam light is inherently, certain applications utilize the coherence of laser diodes. Nick HolonyakOther teams at, and were also involved in and received credit for their historic initial demonstrations of efficient light emission and lasing in semiconductor diodes in 1962 and thereafter. GaAs lasers were also produced in early 1963 in the Soviet Union by the team led by.In the early 1960s liquid phase epitaxy (LPE) was invented by Herbert Nelson of RCA Laboratories. By layering the highest quality crystals of varying compositions, it enabled the demonstration of the highest quality heterojunction semiconductor laser materials for many years. LPE was adopted by all the leading laboratories, worldwide and used for many years.

It was finally supplanted in the 1970s by molecular beam epitaxy and organometallic.Diode lasers of that era operated with threshold current densities of 1000 A/cm 2 at 77 K temperatures. Such performance enabled continuous-lasing to be demonstrated in the earliest days. However, when operated at room temperature, about 300 K, threshold current densities were two orders of magnitude greater, or 100,000 A/cm 2 in the best devices. The dominant challenge for the remainder of the 1960s was to obtain low threshold current density at 300 K and thereby to demonstrate continuous-wave lasing at room temperature from a diode laser.The first diode lasers were homojunction diodes.

That is, the material (and thus the bandgap) of the waveguide core layer and that of the surrounding clad layers, were identical. It was recognized that there was an opportunity, particularly afforded by the use of liquid phase epitaxy using aluminum gallium arsenide, to introduce heterojunctions. Heterostructures consist of layers of semiconductor crystal having varying bandgap and refractive index. Heterojunctions (formed from heterostructures) had been recognized by, while working at RCA Laboratories in the mid-1950s, as having unique advantages for several types of electronic and optoelectronic devices including diode lasers.

LPE afforded the technology of making heterojunction diode lasers. In 1963 he proposed the laser.The first heterojunction diode lasers were single-heterojunction lasers. These lasers utilized aluminum gallium arsenide p-type injectors situated over n-type gallium arsenide layers grown on the substrate by LPE. An admixture of aluminum replaced gallium in the semiconductor crystal and raised the bandgap of the p-type injector over that of the n-type layers beneath. It worked; the 300 K threshold currents went down by 10× to 10,000 amperes per square centimeter. Unfortunately, this was still not in the needed range and these single-heterostructure diode lasers did not function in continuous wave operation at room temperature.The innovation that met the room temperature challenge was the double heterostructure laser. The trick was to quickly move the wafer in the LPE apparatus between different 'melts' of aluminum gallium arsenide ( p- and n-type) and a third melt of gallium arsenide.

It had to be done rapidly since the gallium arsenide core region needed to be significantly under 1 µm in thickness. The first laser diode to achieve operation was a demonstrated in 1970 essentially simultaneously by and collaborators (including ) of the, and and working in the United States. However, it is widely accepted that Zhores I. Alferov and team reached the milestone first.For their accomplishment and that of their co-workers, Alferov and Kroemer shared the 2000 Nobel Prize in Physics.See also.
